Elegant and sophisticated, energy-saving, and power-efficient, with a large LCD luminous panel for convenient night-time operation.

● Includes cooling, heating, and ventilation functions, meeting high air conditioning demands.
● Timed start/stop scheduling: 0 to 24 hours.
● Simple and convenient installation: the panel wiring only requires three signal lines.
● Sleep function: the set temperature will automatically increase by 1°C every hour up to 2°C.
● Temperature sensing method: return air temperature sensing, with a 1.5-meter high-precision temperature sensing wire.
● Dual relay output can separately control electric heater and chilled water valve.

One panel supports linked control of up to 32 fan motor drivers (control boxes) and offers both individual operation and group synchronization functions.

● Key Lock Function: Prevents improper operation.
● Power-off Automatic Sequential Delay Recovery Function: Prevents overload with delayed startup. If the system was in an "on" state before power failure, it will automatically restart in a sequential address coding order when power is restored.
● Safety Design: Includes an 8-amp fuse to protect the fan motor and circuit.
● Power-off Memory: Retains settings for air volume, functional modes, temperature settings, and on/off status.

Return air temperature sensitivity detection.

● Temperature Display Range: 0.0°C ~ 50.0°C, with a minimum display unit of 0.5°C
● Temperature Setting Range: 15°C ~ 35°C, with a minimum setting unit of 0.5°C
● Default Mode: Cooling mode, automatic fan speed, with a set temperature of 26°C
● Applicable to: Central chilled water systems, direct expansion systems.
● Keycard Function: Allows customization of indoor temperature energy-saving mode (optional).
● Four-pipe, electric heating system support available to meet the diverse needs of hotels, hospitals, and dormitories (optional).

Elegant and sophisticated, energy-saving, and power-efficient, with a large LCD luminous panel for convenient night-time operation.

● Includes cooling, heating, and ventilation functions, meeting high air conditioning demands.
● Timed start/stop scheduling: 0 to 24 hours.
● Simple and convenient installation: the panel wiring only requires four signal lines.
● Sleep function: the set temperature will automatically increase by 1°C every hour up to 2°C.
● D Temperature Sensing Method: Senses temperature at the return air inlet, with a 1.5-meter high-precision temperature sensor wire.
● Dual Relay Outputs: Can independently control the electric heater and chilled water valve.

One panel can support the linked control of up to 32 fan drivers (control boxes), with individual operation or synchronized group control functions.

● Button lock function: prevents improper operation.
● Automatic sequential delay recovery function after power failure: overload delay start, when power returns, if the unit was on before power failure, it will power up in sequence according to its address coding.
● Safety design: built-in 8-amp fuse protects the fan motor and circuit.
● Power failure memory: fan speed, function mode, set temperature, on/off status.
